Braze Frogger High Score Save Kit — Features & Install Overview Installation is similar to other Braze Technology save kits (replace the CPU with the daughter card). Frogger’s board set may require extra disassembly/reassembly to reach the CPU and spacer rearrangement or replacement to provide additional clearance between boards. See the detailed install guide for step-by-step photos. Installation Summary Power down and discharge the cabinet; remove the board set. Disassemble the stack as needed to access the CPU; adjust or replace spacers for clearance. Carefully remove the CPU from the Frogger CPU board. Insert the CPU into the included daughter card. Plug the daughter card into the vacated CPU socket, reassemble the board set, and restore spacers. Power on and follow the install guide to verify operation. No soldering or special wiring is required. Key Features Installs in minutes: no board modifications, soldering, or special wiring. High Score Save: stores the top 5 scores and 3-letter initials permanently (no batteries). True Free Play: no coins needed; keep the coin door closed. Full attract mode: runs normally while in Free Play. Initials entry: user-friendly on-screen interface, 3 letters per score. Premium hardware: gold-plated machined header pins; daughter card snaps firmly in place. Power-on diagnostics: automatic self-test each time the game powers up. On-screen settings: adjust options and erase high scores without DIP switch hassle. On-screen test mode: additional checks for sound effects, music, sprites, characters, and color maps. Just the FAQ's Where can I download the install guide? Do I need to solder anything? No. Installation requires no soldering or special wiring. Why do I need extra spacers? The daughter card adds height. Adjusting or replacing spacers ensures proper clearance between stacked boards. How many scores and initials are saved? The kit permanently stores the top 5 scores and 3-letter initials, even after power-off. Can I test audio and video through the kit? Yes. Use the on-screen test mode for sound effects, background music, sprites, characters, and color maps. How do I erase the high score table? Open the on-screen settings menu and select the option to clear high scores.

Braze Space Invaders (Taito) 8-in-1 Multigame High Score Save Kit — Features & Install Overview Easy-to-install kit that expands your Space Invaders boardset to play 8 games. No soldering, special wiring, or external switches required. Switch games by pressing Player 1 + Player 2 Start at the same time to open the on-screen selection menu. Includes on-screen configuration settings and high score save for all games. Note: You may need to install a socket for your 8080 CPU. Please check your PCB. Installation Summary Power down the cabinet and access the Taito SI two-board L-shaped set or 3-PCB stack. Inspect the 8080 CPU. If it isn’t socketed, install a suitable socket. Carefully remove the 8080 CPU from the board. Insert the 8080 into the included daughter card. Plug the daughter card into the vacated 8080 CPU socket on the board. Power on, follow the install guide to verify operation, then press P1+P2 Start to choose a game. Key Features Installs on a Space Invaders PCB in minutes—no soldering or special wiring. Free Play option (see note for Galaxy Wars). High Score Save for all games. Power-on diagnostics at each boot. On-screen configuration settings. Interactive test mode for additional checks. Game List Space Invaders Space Invaders Deluxe Jatre Specter Lunar Rescue Space Laser Balloon Bomber Galaxy Wars (Free Play not supported) Super Earth Invasion FAQ Where can I download the install guide? What board types are supported? Initially supports the Taito black-and-white monitor style boardset in either a two-board L-shaped configuration or a 3-PCB stack. Will it work in a cocktail cabinet? Yes—so long as it’s a black-and-white style cocktail (not the color Taito version). The cabinet’s cocktail/upright behavior depends on sound/input PCB strapping, and screen flip is handled by monitor relays that swap the yoke wires. How do I switch between games? Press P1 Start + P2 Start together to open the game selection menu. How do these versions differ from the originals? Added features include Free Play, diagnostics, and high score save. Sounds are mapped to the eight sound lines available on the SI/SID boardset. Additional options include laser-base count and bonus-award levels (including none). Some titles include extended scoring beyond the originals. Do I need to solder anything? Typically no. If your 8080 CPU is not socketed, you’ll need to add a socket first.

Braze Asteroids Free Play and High Score Save Kit — Features & Install Key Features Installs in minutes — no special wiring or soldering required. Top 10 high scores and initials are saved permanently (no batteries ever). Extended scoring: maximum score increased from 99,990 to 9,999,990. Fix for the Atari REV2 bug that erased the last initial on the 10th score. Compatibility & Included Parts This kit targets the REV2 version of Asteroids. For proper compatibility, a REV2 vector EPROM is required. Refer to the install guide’s “Revisions” section to confirm whether your board is REV1 or REV2. Installation Overview Power down and open your cabinet to access the PCB. Carefully remove the 6502 CPU from the Asteroids board. Insert the 6502 CPU into the included daughter card. Plug the daughter card into the vacated 6502 CPU socket on the board. Power on and follow the install guide to verify operation. How to Clear High Scores Put the game into Self Test (using the cabinet’s self-test switch). While in Self Test, press and hold all four buttons simultaneously: Left, Right, Fire, and Thrust. The screen will immediately display “ERASED”, confirming the high scores were cleared. (Same procedure as Asteroids Deluxe.) FAQ Where can I download the install guide? Download Install Guide (PDF) Do I need to solder anything? No. The kit installs without soldering or special wiring. How long does installation take? Typically just a few minutes with basic PCB handling. Will my scores survive power-off? Yes. The top 10 scores and initials are stored permanently with no batteries required. What is “extended scoring”? The kit raises the maximum score from 99,990 to 9,999,990 to prevent rollover at 100K. Which board revisions are supported? The kit is based on REV2. A REV2 vector EPROM is required and included. Use the install guide to check your current revision. Does it fix the missing last initial on the 10th score? Yes. The included code fixes the REV2 bug that erased the final initial on the 10th entry.

Braze Red Baron High Score Save Kit — Features & Install Overview A simple-to-install high score save kit for Red Baron that permanently remembers the top 7 scores and initials—no batteries required. It also serves as a ROM Saver, reducing issues from aging sockets. Premium gold-plated machined header pins provide a strong, reliable connection and the daughter card snaps firmly into place. No special wiring or soldering is required. Installation Summary Power down the cabinet and access the CPU board. Carefully remove the 6502 CPU from the Red Baron board. Insert the 6502 into the included daughter card. Plug the daughter card into the vacated 6502 CPU socket on the board. Power on and follow the install guide to verify operation. To clear saved scores: enter Self Test (cabinet switch), then press and hold Start + Fire until the screen shows “ERASED.” Key Features Installs in minutes: no board modifications or special wiring; no soldering. Top 7 High Score Save: scores and initials retained permanently (no batteries). ROM Saver: helps avoid problems from old or faulty ROM sockets. Premium hardware: gold-plated machined header pins; daughter card snaps firmly into place. Easy reset: clear the table via Self Test (Start + Fire) with on-screen “ERASED” confirmation. Just the FAQ's Where can I download the install guide? Do I need to solder anything? No. Installation requires no soldering or special wiring. How do I clear the high scores? Enter Self Test, then press and hold Start + Fire until “ERASED” appears on screen. Which CPU does this kit use? The kit interfaces with the 6502 CPU—remove the existing 6502, place it in the daughter card, then insert the card into the 6502 socket. What ensures a reliable connection? Gold-plated machined header pins provide a secure, long-lasting connection to the Red Baron CPU socket.

Congo Bongo Free Play & High Score Save Kit — Features & Install Overview A simple-to-install high score save kit for Congo Bongo that permanently remembers the top 6 scores and initials. It also adds Free Play with full attract-mode screens, a quick power-on self-test (POST), and a flip-screen option for either monitor orientation. Installs in minutes—no board modifications required. Installation Summary Power down the cabinet and access the CPU board. Carefully remove the Z80 CPU from the Congo Bongo CPU board. Insert the Z80 into the included daughter card. Plug the daughter card into the vacated Z80 socket on the CPU board. Power on and follow the install guide to verify operation. No special wiring or soldering is required. Key Features Easy installation: no board modifications or special wiring. High Score Save: permanently remembers the top 6 scores and initials (no batteries). Free Play: full attract mode; enable or disable via DIP switches. Reset High Scores: use Congo Bongo test mode and follow on-screen instructions. Improved Test Mode: clear DIP verification and a mini power-on self test (POST). Flip Screen: supports either monitor orientation. FAQ Where can I download the install guide? Do I need to solder anything? No. Installation requires no soldering or special wiring. How do I reset the high scores? Enter Congo Bongo test mode and follow the on-screen prompts to restore the factory defaults. How do I enable Free Play? Use the DIP switch settings described in the install guide to turn Free Play on or off.
