Xevious Free Play and High Score Save Kit
$66.00
Available, delivery time: 2-5 days
Product information "Xevious Free Play and High Score Save Kit"
Customize Your Xevious Free Play and High Score Save Kit
Build your kit exactly how you want it. Choose a Wi-Fi Enabled Kit or a Standard Save Kit. You can also add a processor and/or a 40-pin socket—optional but recommended for easy installation.
Learn More About This Kit
Click a button to view details, tips, or the installation guide.
Main Features
- Easy install: No soldering, board modifications, or special wiring. Plug in and go.
- Save your scores forever: Uses reliable serial EEPROM (not failure-prone NVRAM or batteries).
- High Score Save: Stores the Top 5 scores with initials.
- Initials entry: 3 characters using Highscoresaves copyright or 10 using NAMCO copyright.
- Copyright: Switch between manufacturer logo or Highscoresaves logo.
- Freeplay: No more coins or opening the coin door.
- Coin Up: Still supports tokens/coins if desired.
- Attract Mode: Minimizes screen burn.
- On-screen DIP settings: Menu-driven DIP control.
- ROM Saver: Remove original program ROMs if desired.
- Cabinet support: Works in Upright and Cocktail cabinets.
Additional Features
- Backup & Restore: Save and restore high scores for events or parties.
- Separate score tables: Different HSS tables for 2, 3, or 4 lives.
- Fast Boot: Self-test available via menu or DIP switches.
- Cross Hatch: Pattern for monitor adjustment.
- RAM / Input Test: Enable RAM and input diagnostics.
Important Installation Notes
- Z80 CPU must be socketed: Install a 40-pin socket if your CPU is soldered.
- Read the Xevious Installation Guide (PDF) before beginning installation.
P1 and P2 start buttons will not light while on Free Play
FAQ
Is installation truly plug-and-play?
Yes. No soldering required. Just ensure your Z80 CPU is socketed.
How many scores are saved and can I enter initials?
Top 5 scores saved. Enter 3 or 10 initials depending on copyright option selected.
What’s the difference between Wi-Fi and Standard kits?
The Wi-Fi kit uploads scores online; the Standard kit saves locally only.
Does it support coins as well as Freeplay?
Yes. You can use Freeplay or coin-up.
What diagnostics and setup tools are included?
Includes Fast Boot, Cross Hatch, and RAM/Input Test features.
Where can I download the Installation Guide?
Do P1/P2 start buttons light up in Free Play?
No. P1 and P2 start buttons will not illuminate while in Free Play.
