Arabian Arcade Free Play and High Score Save Kit PCB Upgrade
Product information "Arabian Arcade Free Play and High Score Save Kit PCB Upgrade"
Arabian Free Play and High Score Save Kit for Original Arcade PCB
Upgrade your original Arabian arcade PCB with reliable free play, high score saving, attract mode enhancements, and optional Wi-Fi leaderboard support while preserving authentic gameplay and original arcade hardware.
Designed specifically for original Arabian arcade hardware, this plug and play upgrade improves long-term reliability without changing gameplay, timing, sound, or the classic arcade experience collectors expect.
Play without coins while retaining optional coin operation.
Reliable serial EPROM storage with no batteries required.
Upload scores online to global arcade leaderboards.
Designed for authentic Arabian arcade PCB gameplay.
Upgrade Your Arabian Arcade Experience
Restore and enhance your original Arabian arcade machine with a professionally designed Free Play and High Score Save Kit built specifically for authentic arcade hardware.
Original boards often lose high scores, rely on aging components, or suffer from unstable resets. This upgrade modernizes your PCB while preserving the original gameplay, sound, timing, and arcade feel that made Arabian a memorable classic arcade game.
Unlike multigame systems or reproduction boards, this kit keeps your original arcade PCB intact while improving long-term reliability for collectors, operators, and restoration projects.
Included Features
- Easy Installation: No soldering, board modifications, or special wiring required
- Permanent Score Saving: Reliable serial EPROM storage with no batteries required
- High Score Tracking: Saves the Top 10 scores using 1 dedicated score table
- Attract Sounds: Adjustable attract audio frequency options
- Free Play Mode: Coin-free operation with optional coin support
- Attract Mode Protection: Helps reduce screen burn from static screens
- Menu-Driven DIP Settings: Configure game settings without opening the cabinet
- ROM Saver: Optionally remove original program ROMs to reduce power usage
- Cabinet Compatibility: Supports Upright and Cocktail cabinets
- Backup and Restore: Save and reload high scores before and after events
- Flip Screen: Instantly corrects screen orientation
Installation Information
- Installation Difficulty: Easy
- Soldering Required: No
- Socketed Z80 Required: Install a 40-pin socket if needed
- Cabinet Compatibility: Upright and Cocktail
- Installation Guide: Download PDF Installation Guide
Optional Wi-Fi Features and Online Leaderboards
Upgrade to a Wi-Fi Enabled Kit to upload scores online and compete against players around the world, locally within your arcade, or across your own connected cabinet network.
Standard kits save scores locally to the PCB, while Wi-Fi kits add automatic online score syncing through the HighScoreSaves global leaderboard platform.
Arabian Free Play and High Score Save Kit FAQ
How many scores are saved?
This kit saves the Top 10 scores using one dedicated score table.
Does it support screen flipping?
Yes. The Flip Screen feature lets you instantly correct screen orientation.
What is the difference between Wi-Fi and Standard kits?
Wi-Fi kits upload scores online and sync to your personal page. Standard kits save locally only.
Is installation truly plug-and-play?
Yes. No soldering or board modifications are required. Ensure your Z80 is socketed or add a 40-pin socket.
Where can I download the Installation Guide?
Login
2 reviews
September 22, 2025 8:58 PM
Great kit for a substandard game, even adds God mode.
Arabian may be rare but we all know it isn't a great game. This kit has the usual bells & whistles, and even a God mode which makes it more fun & helps you learn all the weird ways you can die. Heh
September 10, 2025 12:25 AM
Great highscore save kit
Highscoresaves makes the best arcade highscore save kits. They have the best features and great customer service.
