Bagman Multigame Free Play and High Score Save Kit
Product information "Bagman Multigame Free Play and High Score Save Kit"
HighScoreSaves Bagman and Super Bagman Multigame Kit
Play Bagman and Super Bagman on a documented compatible original Bagman arcade PCB with Free Play, permanent Top 10 score and initials saving for each game, menu-driven settings, separate score tables, backup and restore, and optional Wi-Fi leaderboard support.
This HighScoreSaves daughterboard expands the original Bagman hardware into a two-game system without replacing the arcade PCB with an emulation platform, reproduction board, or multicade computer.
Bagman • Super Bagman
Select Bagman or Super Bagman from the HighScoreSaves menu.
Permanently stores qualifying scores and initials for each game.
Configure supported game, lives, score, and cabinet options on-screen.
Submit supported completed scores to HighScoreSaves leaderboards.
Two Games on Original Bagman Arcade Hardware
The HighScoreSaves Bagman Multigame Kit adds Super Bagman alongside the original Bagman game while retaining the compatible original arcade PCB, cabinet controls, monitor, and sound hardware.
Select this multigame version when both titles are wanted in one cabinet. Choose the separate Bagman Standard Kit when Bagman should remain the only selectable game.
Each included title retains its supported gameplay, controls, graphics, sound, score saving, and configurable operator settings.
Open the HighScoreSaves Game Menu
During attract mode, hold Player 1 Start for approximately four seconds to open the supported game-selection and settings menu.
Games Included
Bagman
The original maze-platform arcade game featuring gold-bag collection, ladders, elevators, mine carts, guards, and route-planning through connected screens.
Super Bagman
The expanded follow-up with additional layouts, faster action, new hazards, and a greater challenge while retaining the familiar Bagman control style.
Free Play and Permanent Score Saving
- Top 10 scores for each game: Retains the ten highest supported Bagman and Super Bagman scores after cabinet power is removed.
- Player initials: Saves qualifying initials with supported high scores.
- Separate game tables: Bagman and Super Bagman maintain their own supported score data.
- Lives-specific score tables: Supported two-, three-, four-, and five-life configurations maintain separate high-score tables.
- Free Play: Start either game without inserting coins.
- Coin operation: Continue accepting quarters or tokens when Free Play is disabled.
- Score backup and restore: Back up and restore supported high-score data through the kit menu.
- High-score reset: Clear supported score data through the settings menu.
- Battery-free storage: Scores, initials, and supported settings use serial EEPROM storage.
Game Selection and Operator Features
- Game-selection menu: Select Bagman or Super Bagman through the on-screen menu.
- Menu-driven DIP settings: Configure supported game and cabinet options without changing physical DIP switches.
- High Scores button: View the supported saved-score table for the selected game.
- Global High Scores button: Access supported leaderboard information when using a Wi-Fi-enabled kit.
- Soft reset: Restart the selected game without switching off cabinet power.
- Fast startup: The kit begins operating shortly after cabinet power is applied.
- Rotating attract displays: Changes supported attract screens rather than continuously showing one static image.
- Saved configuration: Supported game and operator settings remain stored after power-off.
- Upright and cocktail support: Compatible with documented upright and cocktail cabinet configurations.
- ROM Saver operation: Supported original program ROMs may be removed only as directed by the installation guide.
Important PCB and Installation Requirements
- Supported hardware: Designed for documented compatible original Bagman arcade PCBs.
- PCB access required: The original arcade game board must be accessed during installation.
- 40-pin Z80 location: The kit installs at the documented Z80 processor location.
- Original processor: The original Z80 is removed from the PCB and installed on the HighScoreSaves daughterboard unless a compatible processor option is selected.
- No soldering when socketed: Installation does not require soldering when the Z80 location already has a compatible 40-pin socket.
- Soldered processor: If the Z80 is soldered directly to the PCB, a qualified arcade technician must install a compatible 40-pin socket.
- PCB cage clearance: Some cabinets may require temporary removal or adjustment of the PCB cage to provide sufficient clearance for the installed daughterboard.
- ROM removal: Remove only the designated program ROMs identified in the Bagman Multigame installation guide.
- Orientation: Verify Pin 1 alignment and inspect every processor pin before restoring cabinet power.
Installation Information
- Installation type: Multigame daughterboard upgrade for compatible original Bagman hardware
- Included games: Bagman and Super Bagman
- Processor: Compatible Z80 processor
- Processor location: Documented 40-pin Z80 socket
- Soldering required: No, when the required processor location is already socketed
- Possible cabinet requirement: PCB cage removal or adjustment for daughterboard clearance
- Cabinet compatibility: Documented upright and cocktail configurations
- Installation guide: Download the Bagman Multigame installation guide
Standard and Optional Wi-Fi Versions
The Standard Kit permanently saves supported Bagman and Super Bagman scores, initials, settings, and configuration data locally. An internet connection is not required.
The optional 2.4 GHz Wi-Fi Kit includes the same local features and can also submit supported completed scores after qualifying initials are entered.
Wi-Fi can be disabled without affecting game selection, gameplay, Free Play, local score saving, or menu operation.
Bagman Multigame Kit FAQ
Which games are included?
The kit includes Bagman and Super Bagman.
How is the game-selection menu opened?
Hold Player 1 Start for approximately four seconds during attract mode.
How many high scores are saved?
The kit stores the Top 10 supported scores and qualifying initials for each included game.
Are separate score tables supported?
Yes. Bagman and Super Bagman maintain separate supported score data, with lives-specific tables for two-, three-, four-, and five-life settings.
Does this replace the original Bagman PCB?
No. The daughterboard operates with documented compatible original Bagman arcade hardware.
Does installation require soldering?
Not when the required Z80 location already has a compatible 40-pin socket. A qualified arcade technician must install a socket when the processor is soldered directly to the PCB.
Must the PCB cage be removed?
Some cabinet configurations may require temporary PCB cage removal or adjustment to provide enough clearance for the daughterboard.
Is Wi-Fi required?
No. Standard kits save supported scores, initials, and settings locally. Wi-Fi is optional for online score submission.
Where is the installation guide?
