Frontline Multigame Free Play and High Score Save Kit

Product information "Frontline Multigame Free Play and High Score Save Kit"

Upgrade Your Original Taito SJ Frontline Arcade PCB

The HighScoreSaves Frontline Vertical Taito Multigame Free Play and High Score Save Kit transforms compatible original Taito SJ arcade hardware into a seven-game multigame system featuring Frontline, Wild Western, Alpine Ski, Bio Attack, Water Ski, Highway Race, and Space Cruiser. Enjoy Free Play, permanent Top 10 high score saving with player initials, adjustable attract sounds, and optional Wi-Fi leaderboard support. Keep your original Taito SJ PCB stack while adding on-screen settings, separate lives-based score tables, Backup and Restore, advanced operator options, and ROM Saver functionality. This is an original-hardware upgrade, not an emulator or replacement multicade PCB.

Free Play

Play with or without coins

High Score Saving

Top 10 scores saved

with initials!

Attract Sounds

Selectable in settings

Optional Wi-Fi

Upload scores to Personal and Global pages!

Frontline Multigame PCB Compatibility at a Glance

Compatible PCB Original Taito SJ Frontline, Wild Western, Jungle Hunt, or Elevator Action PCB configurations
CPU location Main Z80 at IC56 on CPU board; Sound Z80 at IC52 on Game Board
CPU socket Two compatible 40-pin Z80 sockets required
Installation Two daughtercards, partial PCB-stack disassembly, mandatory program and sound ROM removal; replacement stand-offs required but not included
Cabinet support Documented compatible Taito SJ cabinet configurations; rotary-dial support required for Jungle Hunt or Elevator Action PCB installations
Before you order: Verify your original Taito SJ PCB is compatible. Documented configurations include Frontline, Wild Western, Jungle Hunt, and Elevator Action. Two compatible Z80 processors are required at Main CPU IC56 and Sound CPU IC52. All documented original program and sound ROMs must be removed. Installation requires partial PCB-stack disassembly and replacement PCB stand-offs for proper daughterboard clearance. No stand-offs are included with this kit; customers must obtain suitable replacement stand-offs separately. Rotary-dial support is required when using documented Jungle Hunt or Elevator Action PCB configurations. Review the installation PDF before purchasing.

Choose Your Frontline Multigame Kit Version

Standard Kit

Stores supported Top 10 high scores with player initials, settings, and configuration data locally on the installed HighScoreSaves kit. No internet connection required.

Wi-Fi Enabled Kit

Includes Standard features and can submit qualifying completed scores to the HighScoreSaves global leaderboard using a compatible 2.4 GHz Wi-Fi network.

What's Included

Core kit hardware:

  • 1 × HighScoreSaves Main Z80 Daughter Card
  • 1 × HighScoreSaves Sound Z80 Daughter Card

Two Z80 processors required: The original compatible Main Z80 at IC56 and Sound Z80 at IC52 are transferred to their respective daughtercards during installation.

PCB mounting hardware: Replacement PCB stand-offs are required for proper installation and safe daughterboard clearance. No stand-offs are included with this kit. Customers must obtain suitable replacement stand-offs separately before installation.

Important: Do not leave the documented original program or sound ROMs installed. Their removal is required for correct multigame operation.

Installation & Helpful Guides

Verify your original Taito SJ PCB before installation. The installation requires transferring both Z80 processors, removing documented ROMs, partially disassembling the PCB stack, and checking daughterboard clearance. Replacement PCB stand-offs are required and are not included.

Identify Your Original Taito SJ Arcade PCB Check your original Taito hardware and PCB compatibility before ordering
View Frontline Vertical Taito Multigame Installation Guide PDF Z80 installation, ROM removal, MCU removal, and PCB-stack reassembly
Watch Frontline Multigame Settings Menu Video Review the multigame menu and supported operator settings

Additional Details & Resources

Select any section below to see more details.

Advanced Kit Features
Frontline Original Taito Frontline arcade gameplay included in the vertical multigame collection.
Wild Western Included selectable Taito SJ arcade game.
Alpine Ski Included selectable Taito SJ arcade game.
Bio Attack Included selectable Taito SJ arcade game.
Water Ski Included selectable Taito SJ arcade game.
Highway Race Included selectable Taito SJ arcade game.
Space Cruiser Included selectable Taito SJ arcade game.
Original Taito SJ Hardware Keeps the original compatible CPU, game, video, ROM/RAM, and sound PCB platform in operation rather than replacing the arcade hardware with an emulator or generic multicade system.
Free Play & Coin Operation Start supported games without inserting coins or retain traditional coin-up operation when Free Play is disabled.
Top 10 High Score Saving Permanently saves supported Top 10 high score tables with qualifying player initials for supported games.
Battery-Free Storage Serial EEPROM storage retains supported high scores, initials, and settings without requiring a backup battery or NVRAM.
Separate Score Tables Maintains supported high score tables for 2-, 3-, and 4-life settings.
Backup & Restore Save a backup of supported high score data and restore saved tables through the kit menu.
Adjustable Attract Sounds Configure supported attract sounds at 25%, 50%, or 100% of attract-mode rotations.
Attract-Mode Protection Helps reduce prolonged display of supported static imagery during idle cabinet operation.
On-Screen Settings Configure supported game, DIP-switch, and operator options through the HighScoreSaves settings menu.
High Scores Menu Quickly view supported saved score tables for the selected game.
Reset Option Restart supported gameplay without cycling cabinet power when the option is enabled.
Self-Test Access supported diagnostic functions through the settings menu or documented DIP-switch options.
Continue Enable or disable continue functionality in supported games.
God Mode Provides unlimited-lives practice for supported games. High score saving is disabled while God Mode is active.
Flip Screen Rotate the displayed image 180 degrees when required for a supported installation.
ROM Saver The multigame supplies supported program and sound code after all documented original program and sound ROMs are removed according to the installation guide.
Installation & Settings Access

Game-selection menu: During attract mode, hold Player 1 Start until the multigame selection menu appears.

Protected settings menu: With the cabinet powered off, hold Player 1 Start while turning on the cabinet. Release the button when the on-screen prompt instructs you to continue.

Compatible hardware: This kit is designed for documented compatible original Taito SJ arcade hardware. Supported configurations listed in the product documentation include Frontline, Wild Western, Jungle Hunt, and Elevator Action.

Rotary-dial compatibility: Rotary-dial support is required when installing on the documented Jungle Hunt or Elevator Action PCB configurations. Confirm your original hardware and required controls before ordering.

PCB-stack preparation: Power off the arcade cabinet and disconnect power. Photograph and label the original flat cables, connectors, PCB orientation, spacers, and stand-off locations before partially disassembling the multi-board Taito SJ stack.

Main Z80 at IC56: Remove the original compatible Main Z80 processor from IC56 on the CPU board. Install it on the HighScoreSaves Main Z80 Daughter Card with the correct Pin 1 orientation. Install the completed daughtercard into the original IC56 socket.

MCU at IC24: The installation guide documents removal of the original MCU at IC24 during the main-board installation. Follow the guide for correct handling and component placement.

Sound Z80 at IC52: Remove the original compatible Sound Z80 processor from IC52 on the Game Board. Install it on the HighScoreSaves Sound Z80 Daughter Card with the correct Pin 1 orientation. Install the assembled daughtercard into the original IC52 socket.

Mandatory sound ROM removal: Remove all documented original sound ROMs from IC70 through IC73 as specified in the installation guide.

Mandatory program ROM removal: Remove the original program ROMs from IC1 through IC10 on the ROM board as specified in the installation guide. The kit will not operate correctly if the designated original program or sound ROMs remain installed.

Socket requirements: Compatible 40-pin Z80 sockets are required at both processor locations. No soldering is normally required when both positions are already socketed. If a required Z80 is soldered directly to the original PCB, a qualified arcade technician must remove it and install the appropriate socket.

PCB stand-offs and clearance: Reassemble the original Taito SJ PCB stack using the suitable replacement stand-offs and original spacers specified in the installation guide. No replacement PCB stand-offs are supplied with this kit; they must be obtained separately before installation. Verify that neither daughterboard contacts the video board, CPU board, capacitors, or surrounding components. Check all clearances before reconnecting cables and restoring power.

Top 10 high score saving: Supported games retain Top 10 score tables with qualifying player initials using battery-free serial EEPROM storage. Separate supported tables are maintained for 2-, 3-, and 4-life settings.

Practice and operator options: Supported menu features include attract sound configuration, high score viewing, Backup and Restore, reset, self-test, Continue, God Mode, and Flip Screen. High score saving is disabled during God Mode.

Final installation verification: Confirm Main and Sound Z80 installation, MCU removal where documented, required ROM removal, daughterboard orientation, safe PCB-stack spacing using separately obtained replacement stand-offs, and proper cable connections before powering on the cabinet.

Wi-Fi Setup & Global Scores

The Wi-Fi Enabled version connects to compatible 2.4 GHz Wi-Fi networks to submit qualifying completed scores to HighScoreSaves online leaderboards. Supported Top 10 high scores with player initials continue to be stored locally on the installed kit when Wi-Fi is disabled or unavailable. Free Play, multigame selection, attract sounds, on-screen settings, Backup and Restore, and normal gameplay also work without an internet connection.

The optional Wi-Fi features also provide access to supported Global High Scores displays. Standard kits do not require Wi-Fi for normal operation or local score saving.

Learn About HighScoreSaves Wi-Fi and Global High Scores

Standard vs. Wi-Fi Enabled HighScoreSaves Kits

View Global Arcade High Scores
