$225.00
Product information "Hyper Sports Multigame Free Play and High Score Save Kit"
Play Three Classic Arcade Games on Your Original Konami Hyper Sports PCB
The HighScoreSaves Hyper Sports Multigame Free Play and High Score Save Kit upgrades compatible original Konami Hyper Sports arcade PCBs with three games: Track and Field, Hyper Sports, and Hyper Sports Rearranged. Enjoy Free Play, permanent game-specific high score saving, adjustable attract sounds, attract jingles, and optional Wi-Fi leaderboard support. Additional features include individual event practice, Stealth Mode, Menu Lock, Score Backup and Restore, on-screen settings, and ROM Saver functionality. The kit retains your original Konami arcade hardware, controls, graphics, and sound system rather than replacing the game with a generic emulator or multicade board.
|
Free Play Three games, no coins needed |
High Score Saving Top 10 / 13 / 23 Game-specific tables with initials! |
|
Attract Sounds Selectable in settings |
Optional Wi-Fi Upload scores to Personal and Global pages! |
Three Games Included
Track and Field
Konami's classic Olympic-style sports arcade game.
Top 10 high scores saved
Hyper Sports
The original Konami arcade sports sequel, featuring additional competitive events.
Top 13 high scores saved
Hyper Sports Rearranged
A rearranged sports-game experience combining and changing supported events and their sequence.
Top 23 high scores saved
Each game maintains its own supported high score tables using battery-free serial EEPROM storage. Choose your game through the kit's menu or supported boot-selection settings.
Hyper Sports Multigame PCB Compatibility at a Glance
| Compatible PCB | Documented compatible original Konami Hyper Sports PCB only; original Track and Field PCBs are not compatible |
|---|---|
| CPU requirements | 6809E processor required for the main kit daughtercard; compatible Z80A sound CPU hardware required |
| Required sockets | Upper PCB: Z80 sound CPU at AB18, PROM at C3. Lower PCB: PROMs at A9 and J12 |
| Jumper settings | Documented D10/D11 and F18/F19 configurations must be set to 128, not 64 |
| Cabinet support | Documented upright and 4-player cocktail configurations; original 1–4 player control support |
Choose Your Hyper Sports Multigame Kit Version
Standard Kit
Permanently stores the Top 10 Track and Field, Top 13 Hyper Sports, and Top 23 Hyper Sports Rearranged high scores in separate supported tables using battery-free serial EEPROM storage. Game selection, Free Play, practice events, settings, and local score saving do not require an internet connection.
Wi-Fi Enabled Kit
Includes Standard features and supports submitting qualifying completed scores to the HighScoreSaves online leaderboard platform. Local gameplay, settings, and score saving continue when Wi-Fi is disabled or unavailable.
What's Included
Base kit: HighScoreSaves Hyper Sports / Track and Field / Hyper Sports Rearranged multigame upgrade hardware.
Kit hardware: The installation guide identifies a 6809E daughtercard, sound daughtercard, Konami CPU adapter, game-specific replacement ROM/PROM daughtercards for the documented upper and lower PCB positions, and a connecting ribbon cable.
6809E processor: Required for installation but not included unless selected as an optional CPU when ordering. You may also supply a compatible 6809E processor.
Z80 sound CPU: A compatible Z80A is required at the sound CPU location. Your original compatible processor may be reused if safely removed and working, or a suitable replacement must be provided.
Socketing: The original Hyper Sports PCB must have the documented 40-pin sound CPU socket and three required 16-pin narrow PROM sockets installed. Any needed socketing work is performed separately from the kit installation.
Installation & Helpful Guides
This is a multi-board hardware upgrade, not a simple plug-in CPU-only installation. Carefully review the PDF for the 6809E adapter, sound board, replacement PROM modules, ribbon cable, socket locations, and jumper changes.
| Identify Your Original Hyper Sports Arcade PCB Confirm original Konami hardware before ordering this multigame upgrade |
| View Hyper Sports Multigame Installation Guide PDF Complete 6809E adapter, sound CPU, PROM socket, jumper, daughtercard, and ribbon cable installation |
| Watch Hyper Sports Multigame Settings Menu Video See game selection, practice events, high scores, Menu Lock, and supported settings |
| Hyper Sports Multigame PCB Compatibility Guide Review supported original PCBs, socket requirements, and installation checks |
Additional Details & Resources
Select any section below to see more details.
Advanced Kit Features
| Three Classic Games | Play Track and Field, Hyper Sports, and Hyper Sports Rearranged on documented compatible original Konami Hyper Sports hardware. |
|---|---|
| Original Konami Hardware | Retains the original Hyper Sports PCB platform, graphics, sound, and supported 1–4 player arcade controls without using a generic replacement multicade board. |
| Free Play & Coin Operation | Enjoy Free Play without inserting coins, or retain traditional Coin-Up operation when desired. |
| Track and Field Scores | Permanently stores the Top 10 supported Track and Field high scores. |
| Hyper Sports Scores | Permanently stores the Top 13 supported Hyper Sports high scores. |
| Hyper Sports Rearranged Scores | Permanently stores the Top 23 supported Hyper Sports Rearranged high scores. |
| Battery-Free Storage | Uses serial EEPROM to retain supported high scores and settings without a backup battery or traditional NVRAM. |
| Separate Score Tables | Each of the three supported games maintains its own independent high score tables. |
| Practice Levels | Start directly at supported individual sporting events for focused practice without replaying every earlier event. |
| Game Selection | Select Track and Field, Hyper Sports, or Hyper Sports Rearranged through supported game-selection and startup options. |
| Stealth Mode | Automatically boots into the last played game, providing a more streamlined arcade startup experience. |
| Menu Lock | Helps protect the kit configuration from unauthorized menu changes in shared or public arcade environments. |
| Attract Sounds | Select supported attract-sound operation at 25%, 50%, or 100% of attract-mode rotation intervals. |
| Attract Jingles | Adds supported rotating audio jingles during attract-mode operation. |
| Attract-Mode Protection | Helps reduce prolonged static-screen display during extended idle periods. |
| On-Screen Settings | Configure supported game, gameplay, DIP-switch, and operator settings using the kit's menu system. |
| Score Backup & Restore | Back up supported saved high-score data and restore it through the HighScoreSaves settings menu. |
| High Scores Button | Quickly display supported saved score tables for the selected game. |
| All Global High Scores Button | Provides supported access to global leaderboard information with the Wi-Fi Enabled version. |
| Reset Button | Restart supported gameplay without cycling cabinet power. |
| Bonus Man Options | Configure supported bonus-man options for Track and Field gameplay. |
| ROM Saver | Supports removal of designated original ROMs when the multigame hardware is installed according to the guide. Remove only the documented components. |
| Optional Wi-Fi | Wi-Fi Enabled versions add supported online high score submission while retaining permanent local score saving. |
Installation & Settings Access
Settings menu: With cabinet power off, hold Player 1 Start while turning on the game. Release Player 1 Start when the screen instructs you to continue. The Gyruss-style standard HighScoreSaves settings access is not used as a substitute for the specific Hyper Sports menu and installation instructions.
Compatible original hardware: The kit installs only on documented compatible original Konami Hyper Sports arcade PCBs. It is not compatible with original Track and Field PCBs. Verify that the Hyper Sports board is working correctly before beginning installation.
Installation complexity: This upgrade requires soldering, desoldering, socket installation, jumper changes, and installation of several daughtercards. It is recommended for experienced arcade technicians or owners with suitable electronic repair skills and equipment.
Upper PCB — Z80 sound CPU: The documented AB18 location requires a compatible 40-pin sound CPU socket. If the original Z80A is soldered directly to the board, it must be carefully desoldered and socketed. A compatible Z80A processor must be fitted for operation.
Upper PCB — PROM at C3: The C3 PROM must be removed as documented, and a compatible 16-pin narrow socket installed for the corresponding kit module.
Lower PCB — PROMs at A9 and J12: Both documented lower-board PROM locations require appropriate 16-pin narrow sockets before the corresponding HighScoreSaves daughtercards can be installed.
Main 6809E adapter: The installation guide documents removal of the original 42-pin Konami custom processor module at E/F18, followed by installation of the kit's 6809E adapter and main daughtercard. The kit requires a standard 6809E processor installed on the main daughtercard. Supply your own compatible 6809E or select the optional processor when ordering.
Jumper configuration: The documented jumper groups at D10/D11 and F18/F19 must be configured for 128 rather than 64. Carefully follow the actual PCB markings and the installation guide photographs when moving the jumpers.
Replacement program ROMs: Follow the guide for removing the designated original program ROMs and installing the kit's replacement modules. Do not remove unrelated components based only on their appearance or neighboring positions.
Other daughtercards: Install the documented character, object, video, sound, and PROM replacement daughtercards at their specified upper- and lower-board locations. Maintain correct Pin 1 orientation and fully seat each module.
Ribbon cable: Reconnect the supplied ribbon cable between the upper and lower PCB kit modules using the exact routing shown in the PDF. Verify cable orientation and ensure it is not pinched between the boards.
Board reassembly: Reinstall the original board stack with the documented spacer and standoff arrangement. Confirm that daughtercards, ribbon cables, board edges, and connectors have adequate clearance.
Game selection: Select Track and Field, Hyper Sports, or Hyper Sports Rearranged using the supported menu and startup settings. Stealth Mode can automatically boot the last played game.
Game-specific high scores: The kit permanently stores the Top 10 Track and Field, Top 13 Hyper Sports, and Top 23 Hyper Sports Rearranged high scores in separate supported tables.
Practice levels: Start directly at supported sporting events using the kit's practice-level selections.
Menu Lock: Enable the documented Menu Lock function to help prevent unwanted changes to supported settings.
Attract sounds and jingles: Select supported 25%, 50%, or 100% attract-sound operation and available rotating attract jingles from the on-screen settings.
ROM Saver: Remove only the original ROMs specifically documented for removal in the installation guide. Keep removed original hardware for safekeeping.
Final installation verification: Before powering on, verify the 6809E CPU type, 42-pin adapter position, Z80 sound CPU socket, all three 16-pin PROM sockets, both 128 jumper settings, daughtercard orientation, ribbon cable routing, and original board connectors. If the game fails to start, turn power off and inspect the installation before retrying.
Wi-Fi Setup & Global Scores
The Wi-Fi Enabled Hyper Sports Multigame Kit adds supported online high score submission through the HighScoreSaves leaderboard platform. Local score saving remains available for all three games even when Wi-Fi is disabled or unavailable.
Supported local scores include the Top 10 for Track and Field, Top 13 for Hyper Sports, and Top 23 for Hyper Sports Rearranged. Each game maintains its own supported tables using battery-free serial EEPROM storage.
The kit also provides supported High Scores and All Global High Scores menu functions for accessing applicable local and online leaderboard information.
Free Play, game selection, normal gameplay, practice events, attract sounds, Stealth Mode, Menu Lock, ROM Saver, and on-screen settings do not require an internet connection.
Standard vs. Wi-Fi Enabled HighScoreSaves Kits
Manuals, Schematics & More
Hyper Sports Multigame PCB Compatibility Guide
Hyper Sports / Track and Field / Rearranged Multigame Installation Guide PDF
Hyper Sports Multigame Settings Menu Video
How to Identify Your Original Arcade PCB
How HighScoreSaves Kits Work on Original Arcade PCBs
