Customize Your Time Pilot Free Play and High Score Save Kit Build your kit exactly how you want it. Choose a Wi-Fi Enabled Kit or a Standard Save Kit. You can also add a processor and/or a 40-pin socket—optional but recommended for easy installation. Learn More About This Kit Click a button to view details, tips, or the installation guide. Features Easy install - Plug-and-play with a socketed Z80 board; soldering a 40-pin socket may be required otherwise. Save your scores forever — Uses reliable serial EEPROM (not failure-prone NVRAM or batteries). High Score Save — Stores the Top 5 scores. Attract Sounds — Hear what you’ve been missing; enable sound during attract rotation. Copyright — Switch between manufacturer logo or Highscoresaves logo on attract screen. Freeplay — No more coins or opening the coin door. Coin Up — Still supports coins if desired. Attract Mode — Minimizes screen burn by avoiding static screens. On-screen DIP settings — Menu-driven; no cabinet pull-out to change physical dip switches. ROM Saver — You can remove original program ROMs if desired. Cabinet support — Works in Upright and Cocktail cabinets. Additional Features Backup and Restore — Save and restore high scores (perfect before/after parties). Separate score tables — Different HSS tables for 2, 3, or 4 lives. Fast Boot — Self-test accessible via main menu or by setting all PCB DIP switches to off. Important Ensure your Z80 CPU is socketed; if not, install a 40-pin socket for the kit to work. Read the Installation Guide (PDF) before you install. Just the FAQ's Do I need to solder anything to install this kit? No. Installation is plug-and-play as long as your Z80 is socketed. If it isn’t, install a 40-pin socket first. What’s the difference between the Wi-Fi and Standard kits? The Wi-Fi kit uploads scores online and syncs them to your personal web page. The Standard kit saves scores locally only. Can I upgrade to Wi-Fi later? No. The Wi-Fi hardware must be included at purchase—there’s no post-purchase upgrade path. How many scores are saved? This Time Pilot kit saves the Top 5 scores with initials. Will this work in my cabinet? Yes. The kit supports both Upright and Cocktail Time Pilot cabinets. Can I back up or restore high scores? Yes. Use the Backup/Restore feature to save scores before events and restore them afterward. Does it support attract sounds? Yes. Attract sounds can be enabled during the rotation cycle. What’s the ROM Saver feature? You may remove the original program ROMs to save power—the kit runs the program directly. Does it support Freeplay and Coin Up? Yes. You can start games in Freeplay mode or still use coins/tokens if desired. Where can I find the installation guide? You can download it here: Time Pilot Installation Guide (PDF) .

Customize Your Gyruss Free Play and High Score Save Kit Build your kit exactly how you want it. Choose a Wi-Fi Enabled Kit or a Standard Save Kit. You can also add a processor and/or a 40-pin socket—optional but recommended for easy installation. Learn More About This Kit Click a button to view details, tips, or the installation guide: Features Easy install – Plug-and-play with a socketed Z80 board; soldering a 40-pin socket may be required otherwise. Save your scores forever – Uses reliable serial EEPROM (not failure-prone NVRAM or batteries). High Score Save – Saves the Top 5 scores. Copyright – Switch the attract-screen logo between the manufacturer and Highscoresaves. Freeplay – No more coins or opening the coin door. Coin Up – Still supports coins if wanted. Attract Mode – Minimizes screen burn by preventing static screens. On-screen DIP settings – Menu-driven; no need to open the cabinet to flip switches. ROM Saver – Remove original program ROMs if desired to save power. Cabinet support – Works in Upright and Cocktail cabinets. Additional Features Backup and Restore – Back up high scores and restore later (great before/after game-room parties!). Separate score tables – Different high-score tables for 2, 3, or 4 lives. “Stealth Mode” – Menu is available by pressing Player 1 while powering on. Fast Boot – Self-test accessible via the main menu or by setting all DIP switches on the PCB to off. Extended Scoring – Up to 9,999,990 points. Important Ensure your Z80 is socketed. If not, install a 40-pin socket for the kit to work. Read the Gyruss Installation Guide (PDF) before you begin. Just the FAQ's Does this kit require soldering? Usually no—it’s plug-and-play if your board’s Z80 is already socketed. If your Z80 is soldered directly to the PCB, you’ll need to install a 40-pin socket (soldering required) before the kit will plug in. See the Installation Guide. How many high scores does this kit save? This kit permanently saves the Top 5 high scores. Will Freeplay disable coin usage? No. Even in Freeplay mode, the Coin Up feature still works if you want to use coins. What is “Stealth Mode”? Stealth Mode lets the game boot as if it’s stock. Access it by holding Player 1 during power-on. Can I install this kit in Cocktail cabinets? Yes. The kit supports both Upright and Cocktail cabinets. Where can I find the installation guide? You can download it here: Gyruss Installation Guide (PDF).

Customize Your Pooyan Free Play and High Score Save Kit Build your kit exactly how you want it. Choose a Wi-Fi Enabled Kit or a Standard Save Kit. You can also add a processor and/or a 40-pin socket—optional but recommended for easy installation. Learn More About This Kit Click a button to view details, tips, or the installation guide. Features Easy install: No soldering, board modifications, or special wiring—plug in and go. Save your scores forever: Uses a serial EEPROM (not failure-prone NVRAM or batteries). High Score Save: Saves the Top 10 scores with initials. Attract sounds: Enable at 25%, 50%, or 100% of attract-screen rotations. Free Play: Start games without coins or opening the coin door. Coin Up: Coins/tokens still supported if desired. Attract mode: Reduce screen burn—no more static screens. Menu-driven DIP settings: Change settings on-screen—no cabinet pull-out. ROM Saver: Optionally remove original program ROMs to save power. Cabinet support: Works in upright or cocktail cabinets. Additional Features Backup & restore: Back up high scores and restore later—ideal before/after parties. Separate score tables: Different high-score saves for chosen lives (2, 3, or 4). Reset button: Restart a game without powering off (enable in menu). Important Ensure your Z80 is socketed. If not, install a 40-pin socket for the kit to work. Use a standard Z80: Some PCBs use an encrypted Z80 that will not work with this save kit. Read the installation guide (PDF) before installing. FAQ Do I need to solder anything? No, this kit is plug-and-play. No soldering or board modifications required. Does it save high scores permanently? Yes, scores are stored in EEPROM and do not require batteries. How many high scores does it save? The kit saves the Top 10 scores with initials. Does it support attract sounds? Yes, attract sounds can be enabled at 25%, 50%, or 100% of rotations. Can I use Free Play and coins? Yes, the kit supports both Free Play and Coin Up modes. Will it work in all cabinet types? Yes, it works in both upright and cocktail cabinets. Can I back up and restore scores? Yes, scores can be backed up and restored later—great before and after events. Does it provide separate score tables? Yes, separate tables are saved based on chosen life settings (2, 3, or 4). What CPUs are compatible? A standard socketed Z80 must be used. Encrypted Z80 CPUs will not work with this kit. Where can I download the installation guide? You can download it here: Pooyan Installation Guide (PDF)

Customize Your Roc 'n Rope Free Play and High Score Save Kit Build your kit exactly how you want it. Choose a Wi-Fi Enabled Kit or a Standard Save Kit. You can also add a processor and/or a 40-pin socket—optional but recommended for easy installation. Learn More About This Kit Click a button to view details, tips, or the installation guide. Features Easy install – No soldering, board modifications or special wiring. Plug in and go! Save your scores forever – We use a serial EPROM, not failure-prone NVRAM or batteries. High Score Save – Saves the Top 5 scores. Enter your initials – Now able to enter your initials with high score. Attract Sounds – Hear what you've been missing! Set at 100% of the attract screen rotation have sound! Freeplay – No more coins or opening up the coin door. Coin Up – Still supports coins if wanted. Attract Mode – Minimize your screen burn. No more static screens. Change DIP settings – Menu-driven. No more pulling out your game to change dip switches. ROM Saver – You can remove original program ROMs if desired to save power. Support – Can be used in an Upright or Cocktail cabinet. Additional Features Separate score tables – 16 different HSS tables (one for every difficulty and lives setting). Backup and Restore – Back up high scores and restore them later (perfect before/after game room parties). Important This kit requires a 6809E to run. Ensure your processor is socketed. If not, you will need to install a 40-pin socket for the kit to work. Read the Installation Guide (PDF) before you install. Just the FAQ's Do I need to solder anything? No, this kit is plug-and-play. No soldering or board modifications are required. Does it save high scores permanently? Yes, high scores are saved to a serial EPROM and remain even without power. How many scores are saved? The kit saves the Top 5 scores with initials. Can I enter my initials? Yes, you can now enter initials for saved high scores. Does it support attract sounds? Yes, attract sounds play at 100% of attract screen rotations. Can I use Freeplay and coins? Yes, the kit supports both Freeplay and Coin Up modes. Does it support both cabinet types? Yes, it works in Upright and Cocktail cabinets. Does it support separate score tables? Yes, 16 different score tables are maintained depending on difficulty and lives settings. What processor is required? A socketed 6809E CPU is required for this kit to function. Where can I download the installation guide? You can download it here: Roc 'n Rope Installation Guide (PDF)

VS Nintendo Red Tent | Dual Upright Multigame Kit The newest Multi VS kit—now upgraded with head-to-head play, 4-player support on compatible titles, on-panel game switching, and more. Key Features On-panel game switching — On the right side of control panel, hold P4 and move the joystick Left/Right to swap games on that side. Coin Up shortcut — Hold P4 for ~5 seconds to coin up. Head-to-Head play — Play VS titles facing off across both sides. 4-player support (title-dependent) — Play games like Wrecking Crew, Balloon Fight, and Tennis head-to-head on Red Tent or Dual Upright. NES Zapper support — Use a Zapper gun with the optional Zapper Adapter. Independent resets — Reset either side without interrupting the other. EPROM-socket compatible — Designed for VS PCBs that use EPROM sockets. Up to 16 total games — 8 games per side (depends on your PPU/Game Pak). Additional Information Your kit ships with a Game Pak for your specific PPU; see game lists below. You can remove original program EPROMs and play from the kit’s Game Pak selection. Tetris and Battle City require correct color palette DIP settings on the original PCB (matching original behavior). Important Compatible cabinets: VS Red Tent or VS Dual Screen Upright. Game list depends on your PPU (0001, 0002, 0003, 0004, or 2C03B). See the PPU Game Pak sections below. Identify your PPU: it usually has a heatsink; the part number (e.g., 0002) appears in the middle of the chip. Read the installation guide before setup — VS Red Tent / Dual Upright Multigame Installation Guide (PDF) . Game Paks by PPU PPU 0001 Standard: Mighty Bomb Jack, Pinball, Battle City, Excitebike, SMB, Skate Kid, Mach Rider, Tetris With Gun: Mighty Bomb Jack, Battle City, Excitebike, SMB, Mach Rider, Tetris, Hogan’s Alley, Duck Hunt With Gun | Special “Head-to-Head”: SMB, Excitebike, Tetris, Wrecking Crew, Balloon Fight, Tennis, Hogan’s Alley, Duck Hunt Special “Head-to-Head”: SMB, Excitebike, Tetris, Mighty Bomb Jack, Battle City, Wrecking Crew, Balloon Fight, Tennis PPU 0002 Standard: Mighty Bomb Jack, Excitebike, SMB, Slalom, Tetris, Battle City, Mach Rider, Golf (Single Sided) With Gun: Mighty Bomb Jack, Battle City, Excitebike, SMB, Slalom, Tetris, Hogan’s Alley, Duck Hunt With Gun | Special “Head-to-Head”: SMB, Excitebike, Tetris, Wrecking Crew, Balloon Fight, Tennis, Hogan’s Alley, Duck Hunt Special “Head-to-Head”: SMB, Excitebike, Tetris, Mighty Bomb Jack, Slalom, Wrecking Crew, Balloon Fight, Tennis PPU 0003 Standard: Mighty Bomb Jack, Excitebike, SMB, Pinball, Tetris, Battle City, Skate Kid, Soccer With Gun: Mighty Bomb Jack, Battle City, Excitebike, SMB, Soccer, Tetris, Hogan’s Alley, Duck Hunt With Gun | Special “Head-to-Head”: SMB, Excitebike, Tetris, Wrecking Crew, Balloon Fight, Tennis, Hogan’s Alley, Duck Hunt Special “Head-to-Head”: SMB, Excitebike, Tetris, Mighty Bomb Jack, Battle City, Wrecking Crew, Balloon Fight, Tennis PPU 0004 Standard: Excitebike, SMB, Clu Clu Land, Tetris, Battle City, Skate Kid, Ice Climber, Pinball With Gun: Clu Clu Land, Ice Climber, Excitebike, SMB, Tetris, Mighty Bomb Jack, Hogan’s Alley, Duck Hunt With Gun | Special “Head-to-Head”: Clu Clu Land, Ice Climber, Tetris, Wrecking Crew, Balloon Fight, Tennis, Hogan’s Alley, Duck Hunt Special “Head-to-Head”: SMB, Excitebike, Tetris, Clu Clu Land, Ice Climber, Wrecking Crew, Balloon Fight, Tennis PPU 2C03B Standard: Ninja Jajamaru Kun, Excitebike, SMB, Star Luster, Tetris, Battle City, Skate Kid, Mighty Bomb Jack With Gun: Ninja Jajamaru Kun, Excitebike, SMB, Star Luster, Tetris, Mighty Bomb Jack, Hogan’s Alley, Duck Hunt With Gun | Special “Head-to-Head”: Ninja Jajamaru Kun, Excitebike, SMB, Wrecking Crew, Balloon Fight, Tennis, Hogan’s Alley, Duck Hunt Special “Head-to-Head”: Ninja Jajamaru Kun, Excitebike, SMB, Tetris, Mighty Bomb Jack, Wrecking Crew, Balloon Fight, Tennis FAQ Which cabinets does this kit support? VS Red Tent and VS Dual Screen Upright only. What if I want to play Tennis, Balloon Fight or Wrecking Crew? You need to choose the “Head-to-Head” Game Paks for your PPUs. These titles support up to 4 players and must be selected to use both screens. How do I switch games? On the right side, hold P4 and move the joystick Left/Right to swap games on that side. How do I coin up quickly? Hold the P4 button for about 5 seconds. Does it support head-to-head and 4-player games? Yes. Titles such as Wrecking Crew, Balloon Fight, and Tennis support head-to-head on Red Tent/Dual Upright. 4-player depends on the game. Can I use a NES Zapper? Yes, with the optional Zapper Adapter. See Game Pak “With Gun” options for supported titles. Do the two sides reset independently? Yes. You can reset one side without interrupting the other player. Why do some games require DIP color palette changes? Tetris and Battle City follow the original PCB behavior and need correct palette DIPs set on the PCB. How do I know which PPU I have? The PPU usually has a heatsink. Look for a number printed on it (e.g., 0001, 0002, 0003, 0004, or 2C03B). How many games can I install? Up to 16 total—8 per side, depending on your PPU and chosen Game Pak. Where can I download the installation guide? Right here: VS Red Tent / Dual Upright Multigame Installation Guide (PDF) .
