Centipede Free Play and High Score Save Kit

Customize Your Ms Pacman Free Play and High Score Save Kit Build your kit exactly how you want it. Choose a Wi-Fi Enabled Kit or a Standard Save Kit. You can also add a processor and/or a 40-pin socket — optional but recommended for easy installation. Learn More About This Kit Click a button to view details, tips, or the installation guide. Features Easy install — No soldering, board modifications, or special wiring. Plug in and go. Save your scores forever — Uses reliable serial EPROM (not NVRAM or batteries). High Score Save — Saves the Top 10 scores with initials. Attract Sounds — Set to 25%, 50%, or every attract screen. Freeplay — No more coins or opening the coin door. Coin Up — Still supports coins if desired. Attract Mode — Minimizes screen burn; no static screens. Menu-driven DIP settings — Change DIP switches without opening your game. ROM Saver — Optionally remove original program ROMs to save power. Cabinet support — Works in Upright and Cocktail cabinets. Additional Features Backup & Restore — Back up high scores and restore later (great before/after parties). Fast or Original versions — Play either mode. Extended scoring — Saves up to 9,999,990 points (7-digit saves). No more rollovers. Separate high score tables — Distinct tables for Fast vs original play.Play the infamous Kill Screen - Start at Level 255 (Selectable in menu) Stealth Mode — Choose which game the kit boots to. Important Ensure your Z80 is socketed. If not, install a 40-pin socket for the kit to work.You can use on a standard Pacman pcb OR a Ms Pacman pcb. Program roms in row 6 MUST be removed with kit installed5E and 5F must be present Read the installation guide (PDF) before you install. Game List Ms. Pac-Man (Fast version) Ms. Pac-Man (Original/Slow version) Just the FAQ's Do I need to solder anything? No, the kit is plug-and-play. No soldering or board modifications required. Does it save my high scores permanently? Yes, scores are stored on reliable serial EPROM and don’t need batteries. How many high scores does it save? The kit saves the Top 10 scores with initials. Can I still use coins? Yes, the kit supports both Free Play and Coin Up modes. Does it support attract sounds? Yes, you can set sound frequency to 25%, 50%, or every attract screen. Will it work in my cabinet type? It supports both Upright and Cocktail cabinets. Can I back up my high scores? Yes, you can back up and restore scores — great before/after events. Does it save extended scores? Yes, it saves scores up to 9,999,990 points with 7-digit scoring. Can I choose which game it boots into? Yes, with Stealth Mode you decide which version loads at startup. Where can I download the installation guide? You can download it here: Ms. Pac-Man Installation Guide (PDF)

Customize Your Dig Dug Free Play and High Score Save Kit Choose between a Wi-Fi Enabled Kit or a Standard Save Kit. You may also add a processor and/or a 40-pin socket—optional but recommended for easy installation. Learn More About This Kit Click a button below to view product details, setup tips, or the installation guide. Features Easy install: No soldering or board mods. Plug in and play. Permanent score saving: Uses serial EEPROM (not batteries or NVRAM). High Score Save: Stores the Top 5 scores. Freeplay mode: No coins needed, but Coin Up is still supported. Attract Mode: Prevent screen burn with attract mode rotation. On-screen DIP settings: Adjust options without opening the cabinet. ROM Saver: Remove original program ROMs to save power. Cabinet support: Works in Upright and Cocktail machines. Additional Features Backup & Restore: Save and reload high scores—ideal for parties or tournaments. Separate score tables: Maintains different high-score tables for 2, 3, 4, or 5 lives. Important Ensure your Z80 is socketed. If not, install a 40-pin socket for the kit to work. Read the Dig Dug Free Play and High Score Save Kit Installation Guide / Manual (PDF) before setup. Note: In Freeplay mode, P1 and P2 will not flash when starting a game. Just the FAQ's How many scores are saved? This kit saves the Top 5 scores. Does it support Freeplay and coin operation? Yes. You can enable Freeplay or keep Coin Up enabled for quarters/tokens. Are there separate score tables for lives? Yes. It maintains separate tables for 2, 3, 4, and 5 lives. What does ROM Saver do? It allows you to remove the original program ROMs and run the program from the kit, reducing power and wear. Which processor does this kit require? A Z80 is required. Ensure it is socketed or install a 40-pin socket before setup. Are there any limitations in Freeplay mode? Yes. In Freeplay, P1 and P2 will not flash when starting a game. Where can I download the Installation Guide? Download it here: Download the Dig Dug Free Play and High Score Save Kit Setup Instructions / Installation Manual (PDF) . Resources Dig Dug Free Play and High Score Save Kit — Installation Guide / Manual (PDF) HighScoreSaves YouTube Channel — Installation Tips HighScoreSaves Facebook Page HighScoreSaves Reddit Community

Customize Your Popeye Free Play and High Score Save Kit Build your kit exactly how you want it. Choose a Wi-Fi Enabled Kit or a Standard Save Kit. You can also add a processor and/or a 40-pin socket—optional but recommended for easy installation. Learn More About This Kit Click a button to view details, tips, or the installation guide. Features Easy install: No soldering, board modifications, or special wiring—plug in and go. Save your scores forever: Uses a serial EEPROM (not failure-prone NVRAM or batteries). High Score Save: Saves the Top 5 scores with initials. Attract sounds: Toggle ON/OFF during the attract-screen rotation. Free Play: Start games without coins or opening the coin door. Coin Up: Coins/tokens still supported if desired. Attract mode: Reduce screen burn—no more static screens. Menu-driven DIP settings: Change settings on-screen—no cabinet pull-out. ROM Saver: Optionally remove original program ROMs to save power. Cabinet support: Works in upright or cocktail cabinets. Additional Features Backup & restore: Back up high scores and restore later—ideal before/after parties. Separate score tables: Different tables for chosen lives (2, 3, or 4). Reset button: Restart a game without powering off (enable in menu). Self test: Accessible via the main menu, or by setting all PCB DIP switches to OFF. Important Ensure your Z80 is socketed. If not, install a 40-pin socket for the kit to work. Read the installation guide (PDF) before installing. Just the FAQ's Do I need to solder anything? No, this kit is plug-and-play. No soldering or board modifications are required. Does it save scores permanently? Yes, high scores are stored in EEPROM and will remain saved without batteries. How many scores are saved? This kit saves the Top 5 scores with initials. Does it support attract sounds? Yes, attract sounds can be toggled ON or OFF during attract mode. Can I use Free Play and Coin Up? Yes, the kit supports Free Play while still allowing Coin Up mode if desired. Will it work in both cabinet types? Yes, it supports upright and cocktail cabinets. Can I back up and restore scores? Yes, you can back up and restore scores—ideal for before/after events. Does it include a self-test? Yes, the kit includes a self-test accessible via the menu or by setting all DIP switches OFF. Can I remove original program ROMs? Yes, the ROM Saver feature lets you remove original program ROMs to reduce power use. Where can I download the installation guide? You can download it here: Popeye Installation Guide (PDF)

Customize Your Battlezone Free Play and High Score Save Kit Build your kit exactly how you want it. Choose a Wi-Fi Enabled Kit or a Standard Save Kit. You can also add a processor and/or a 40-pin socket—optional but recommended for easy installation. Learn More About This Kit Click a button to view details, tips, or the installation guide. Main Features Easy install: No soldering, board modifications, or special wiring—just plug the kit in and go. Save your scores forever: Uses serial EEPROM (not failure-prone NVRAM or batteries). High Score Save: Stores the Top 10 scores. Attract sounds: Set to 25%, 50%, or 100% of the attract screen rotation. Freeplay: No more coins or opening the coin door to start a game. Coin up: Keep quarters or tokens enabled if you want. Attract mode: Minimizes static screens to help reduce screen burn. Copyright message: Choose original manufacturer or High Score Saves. Change DIP settings: On-screen menu—no manual DIP switches. ROM Saver: Original program ROMs can be removed; program resides on the save kit. Cabinet compatibility: Works in Upright or Cocktail cabinets. Additional Features Backup & Restore: Back up high scores and restore later—perfect before/after parties. Reset button: Restart a game without turning off the cabinet (enable in menu). Separate score tables: Unique high-score tables for different lives selected (2/3/4/5). Fast boot: No waiting for initialization. Important Installation Notes Socketed 6502 required: If your 6502 isn’t socketed, install a 40-pin socket for this kit to work. Read the Battlezone Free Play and High Score Save Kit Installation Guide / Manual (PDF) before setup. FAQ How many scores are saved? The kit saves the Top 10 scores. Does it support Freeplay and coin operation? Yes. You can use Freeplay for convenience or keep coin-up enabled. Can I change DIP settings without opening the cabinet? Yes. DIP switch settings are available in the on-screen menu. What is the Reset Button feature? Enable the Reset Button in the menu to restart a game without powering off. Does it have separate score tables? Yes. The kit maintains separate high-score tables for different lives chosen (2/3/4/5). Does it support fast boot? Yes. It has a fast boot with minimal initialization time. Can I change the copyright message? Yes. You can display either the original manufacturer or High Score Saves branding. Where can I download the Installation Guide? You can download it here: Download the Battlezone Free Play and High Score Save Kit Setup Instructions / Installation Manual (PDF) . Do I need a socketed CPU? Yes. A socketed 6502 is required. If your board doesn’t have one, install a 40-pin socket. Resources Battlezone Free Play and High Score Save Kit — Installation Guide / Manual (PDF) HighScoreSaves YouTube Channel — Installation Tips HighScoreSaves Facebook Page HighScoreSaves Reddit Community

Customize Your Galaga Free Play and High Score Save Kit Build your kit exactly how you want it. Choose a Wi-Fi Enabled Kit or a Standard Save Kit. You can also add a processor and/or a 40-pin socket—optional but recommended for easy installation. Learn More About This Kit Click a button to view details, tips, or the installation guide. Key Features Easy installation — No soldering, board modifications, or special wiring. Plug in and go. Permanent score saving — Uses a serial EPROM, not failure-prone NVRAM or batteries. High Score Save — Saves the Top 5 scores. Real attract sounds — Switchable: off, 25%, 50%, or 100% of the time. Attract sound emphasis — Hear full attract-screen rotation audio when set to 100%. Freeplay — No coins or opening the coin door; Coin Up still supported. Attract mode screen saver — Reduces burn-in from static screens. Menu-driven DIP settings — Change options without pulling the game out. ROM saver — Optionally remove original program ROMs to reduce power use. Cabinet support — Works in Upright or Cocktail cabinets. Additional Features Backup & restore high scores — Ideal for before/after game-room parties. Separate score tables — Different high-score tables for 2, 3, 4, or 5 lives. Wide PCB compatibility — Installs on Midway, Namco, and some clone PCBs. Attract logo choice — Switch copyright to Midway, Namco, or HighScoreSaves. Auto fire option — Toggle on/off via the on-screen game menu. Extended scoring — Up to 99,999,990 (8-digit scores). Level 255 fix — Progress beyond 255 levels (difficulty caps at 255; counter continues). Four shooting speeds — Normal, Slow, Fast, Fastest. Important Notes Ensure your Z80 is socketed; if not, install a 40-pin socket for the kit to work. Read the Galaga Installation Guide (PDF) before you begin. Just the FAQ's Which PCBs are supported? This kit works on Midway, Namco, and some clone Galaga PCBs. How many scores are saved? The kit saves the Top 5 high scores, with backup and restore options. Does it support Freeplay and Coin-Up? Yes, you can run the game in Freeplay mode or keep Coin Up enabled. Are attract sounds adjustable? Yes, attract sounds can be set to play at Off, 25%, 50%, or 100% rotation. What are the advanced options? Advanced features include Auto Fire, Extended Scoring up to 99,999,990, and the Level 255 fix. Where can I download the Installation Guide? Download it here: Galaga Installation Guide (PDF).
